NGH air filter with baffle
Mainly used in the electronics, pharmaceutical industry, clean rooms, laminar flow equipment and other places requiring ultra-high cleanliness
Features:
1. High efficiency H14 filtration efficiency: filtration efficiency for particles ≥0.3μm is above 99.995%
2. High efficiency H13 filtration efficiency: filtration efficiency for particles ≥0.3μm is above 99.97%
3. Sub-high efficiency H10 filtration efficiency: filtration efficiency for particles ≥0.5μm is above 95%
4. Medium efficiency F8 filtration efficiency: filtration efficiency for particles ≥1.0μm is above 80%
5. Special glass fiber filter paper as filter material
6. Special aluminum foil or paper spacer
7. Each filter is strictly tested
8. Available in wood, aluminum alloy, steel plate and stainless steel frames
9. Can be customized according to specific user requirements
Application:
Mainly used in electronics, pharmaceutical industries, clean rooms, laminar flow equipment and other occasions requiring ultra-high cleanliness.
Technical parameters (common specifications)
| Model | Dimensions | Filter area（㎡） | Rated air volume (m³/h) | Initial pressure drop (Pa) | |||||
| Width*Height*Thickness(mm) | Standard | High air volume | Standard | High air volume | F8 | H10 | H13 | H14 | |
| NGH230 | 230×230×110 | 0.8 | 1.4 | 110 | 180 | ≤85 | ≤175 | ≤235 | ≤255 |
| NGH320 | 320×320×220 | 4.1 | 6.1 | 350 | 525 | ||||
| NGH484/10 | 484×484×220 | 9.6 | 14.4 | 1000 | 1500 | ||||
| NGH484/15 | 726×484×220 | 14.6 | 21.9 | 1500 | 2250 | ||||
| NGH484/20 | 968×484×220 | 19.5 | 29.2 | 2000 | 3000 | ||||
| NGH630/05 | 315×630×220 | 8.1 | 12.1 | 750 | 1200 | ||||
| NGH630/10 | 630×630×220 | 16.5 | 24.7 | 1500 | 2250 | ||||
| NGH630/15 | 945×630×220 | 24.9 | 37.3 | 2200 | 3300 | ||||
| NGH630/20 | 1260×630×220 | 33.4 | 50.1 | 3000 | 4500 | ||||
| NGH610/03 | 305×305×150 | 2.4 | 3.6 | 250 | 375 | ||||
| NGH610/05 | 305×610×150 | 5 | 7.5 | 500 | 750 | ||||
| NGH610/10 | 610×610×150 | 10.2 | 15.3 | 1000 | 1500 | ||||
| NGH610/15 | 915×610×150 | 15.4 | 23.1 | 1500 | 2250 | ||||
| NGH610/20 | 1220×610×150 | 20.6 | 30.9 | 2000 | 3000 | ||||
| NGH610/05X | 305×610×292 | 10.1 | 15.1 | 1000 | 1500 | ||||
| NGH610/10X | 610×610×292 | 20.9 | 31.3 | 2000 | 3000 | ||||
| 1. If there are any changes in specifications or structures, the latest data provided by our company shall prevail. 2. Our company accepts orders for products that do not meet the specifications listed above. |
|||||||||
