Medium effect flame retardant air filter
Medium-efficiency air purification, factory direct delivery, support non-standard customization
1. Cleanliness CLASS100 conforms to ISO1466-1 international standard.
2. Adopting adjustable air volume and low noise fan system to ensure that the wind speed in the working area is always in the ideal state.
3. The box body steel plate electrostatic spraying bright and smooth, the operating table surface is 304 stainless steel.
Vertical flow clean worktable description: 1.with brake casters peal foot cup 3.bracket 4.stainless steel table 5.socket 6.glass 7.fluorescent lamp 8.control switch 9.high efficiency filter 10.primary filter 11.fan
Technical parameters (common specifications)
| model number | NMSJ-1000 | NMSJ-1350 | NMSJ-1640 | NMSJ-1950 |
| External Dimension(mm) | W1000xL650XH1750 | W1350xL650XH1750 | W1640xL650XH1750 | w1950xL650XH1750 |
| Air shower size(mm) | W820XL610XH600 | W1270XL610XH600 | W1560XL610XH600 | W1870XL610XH600 |
| Air volume (m/h) | 90o | 1100 | 1500 | 1800 |
| Wind speed (m/h) | 0.45m/s±20% | |||
| Purification level | Class 100 (ISO 14644-1 international standard) | |||
| High Efficiency Filter Efficiency | 99.99%@0.3um | |||
| HEPA Filter Size | 880X570x69 | 1170X570x69 | 915x570x69 610x570x69 | 915x610x69 |
| Number of high-efficiency filters | 1-1 | 2 | ||
| Table vibration half-peak | The table and the overall frame are separated and vibration-free (optional). | |||
| Worktop Material | 304 sanded stainless steel | |||
| noises | <50dB | <50dB | <50dB | <50dB |
| Noise test location | 20cm from the front of the workbench, 1.2m above the ground. | |||
| Supply Voltage | 220VAC 50Hz | |||
| Number of applicants | 1-2 | 2-3 | 3-4 | |
1、In case of changes in specifications and structure, the latest data provided by the company shall prevail.
2、The company accepts the order of the products which are not on the specification of the table.
